MIA Inner Loop & Fast Purification Ventilator
混风机-混风内循环快速净化室内空气
The MIA Mixed Air Fan Fresh Air System offers multiple optional operation modes: it draws outdoor air into the device while simultaneously extracting indoor air, filters it, and then delivers fresh air back into the room. If the outdoor air quality is poor, the device's air damper can be closed, allowing a one-click switch to indoor circulation mode for rapid purification of indoor air. The system is equipped with a silent fan, available in DC/AC options, with brushless DC models standing out in both power efficiency and noise reduction during smooth operation. The filtration section can be optionally configured with washable pre-filters, HEPA filters, high-voltage electrostatic dust removal modules, or customized coconut shell activated carbon filters. Additionally, the system supports optional smart PM2.5 and CO2 air quality monitoring with a WiFi controller, along with Modbus RS485 communication interfaces, meeting high-end personalized needs such as air quality monitoring, remote control, and centralized building management.
MIA米亚混风机新风系统，有多种选配工作模式：将室外的空气抽入设备中，同时将室内的空气抽入设备中，进行过滤后将新鲜空气送入室内。如果室外的环境空气较差，可以关闭设备中的风阀，一键切换室内循环模式对室内的空气进行快速净化。设备配备静音型风机，DC直流/AC交流可选，直流无刷机型平稳运行时功耗及静音表现尤为突出；设备过滤段可选配可水洗初效滤网、HEPA高效滤网、高压静电除尘模块、也可以定制椰壳活性炭滤网；设备可选配智能PM2.5、CO2空气质量监测WIFI控制器并配备Modbus RS485通讯接口，可以满足空气质量监测、远程控制、楼宇集中控制等高端个性化需求。
High-voltage Electrostatic Precipitator：The high-voltage electrostatic precipitator adopts the pin-type electric field discharge method to replace the traditional tungsten wire high-voltage removal method. The thickness is only 4cm, suitable for various kinds of our models, PM2.5 removal rate is highly to 98%. Also it can effectively kill bacteria to prevent the infection. It can be washed or cleaned with brush, no need to be replaced, greatly save the cost.
高压静电除尘杀菌模块：采用针式电场放电方式，代替传统钨丝高压静电集尘方式，模块厚度仅为4cm，可灵活适用于各种机型，对于PM2.5的去除效率高达98%。维护时可用清水进行湿洗，也可以用毛刷刷去集尘格中的灰尘，无耗材产生可反复使用，无需担心使用成本。
High Efficiency Particulate Air (HEPA-H13) Filter：The thickness of this filter is only 3cm. The plastic frame has higher sealing than paper frame, and we use the environmental friendly imported sealant, no color & odor, to ensure healthy and avoid pollution. The raw material of this HEPA filter is from 3M, European standard H13 level. PM2.5 removal rate can be up to 99.97%, and the large dust holding capacity can save the total cost of consumables.
H13级HEPA高效滤网：采用塑料边框，密封性能远超于纸边框，抽拉时平滑无摩擦感；密封胶采用无色无味环保进口胶，确保健康无污染；滤芯采用3M高效HEPA材质，过滤等级为欧标H13级，对于PM2.5的去除效率高达99.97%，超大容尘量为您最大限度节约耗材成本。
Primary Activated Carbon Filter：The plastic frame of this filter seals better than the paper frame, and it is only 2cm thick. The filter is made of composite fiber sprayed with activated carbon powder that can filter out dust particle efficiently. The wind resistance of this filter is very low. The method of spraying makes the activated carbon powder more evenly distributed, which can maximize the effect of activated carbon. This washable filter can be used repeatedly and the combination of primary filter with activated carbon can greatly save your cost of consumables.
初效活性炭二合一滤网：采用塑料边框，密封性能远超于纸边框，抽拉时平滑无摩擦感；滤芯采用复合纤维表面喷涂活性炭粉末，有效过滤粉尘大颗粒，且风阻小，粉末喷涂式活性炭使活性炭分部更均匀，最大化的发挥活性炭的作用。该滤网可用清水清洗反复使用，初效活性炭二合一的方式更是大大降低了耗材使用成本。
